WSZ-10S Dry and wet concrete shotcrete machine for sale

Description:

WSZ-10S Dry and wet concrete shotcrete machine for sale is a multifunctional rotor type machine for wet and dry spraying and conveying. The materials which can be sprayed and conveyed are concrete, mortar, refractory, sand, pea gravel and crushed stone.
Compared with traditional shotcrete machines, WSZ-10S Dry and wet concrete shotcrete machine has the advantages of being lighter and more compact. By changing the rotor of different sizes and adjusting the motor speed, the theoretical displacement range is 0.7~10m3/h, which can better meet the needs of customers. In addition, WSZ-10S Dry and wet concrete shotcrete machine is equipped with rubber sealing plate lubrication system, which can effectively reduce the wear of rubber plate, longer service life and better sealing effect.

Mobile Phone: +86-19913803800
E-mail: sales@wodetec.com

Features

1. The oretical output from 0.7 up to 10 m3/h.

2.Easily overcome obstacles of long or high conveying distances (dry mix).

3.Less dust development.

4.Reduced rebound.

5.For concrete repair, slope stabilization, excavation support or in mining.

6.Light and compact machine design.

7.Stepless adjustment of conveying capacity.

8.Remote control.



Technical Paremeter

Name

Data

Machine Type

Rotary machine WSZ-10S

Process

Thin-stream

Motor power

7.5 kw

Power supply

3X380-480V. 50/60Hz

Rotor size   in liters

2.7           7     10       13

The oretical  output in m3/h ①

0.7-2.0       2.0-5.3       2.9-7.6      3.7-10

Recommended hose sizes

64×85 mm

Grain sizes   in mm

20 mm

Max.conveying distance in m horizontal/vertical



Dry:      300/100

Wet:     40/15

Dimensions in mm





Length      1940

Height    H1

Width   856

Weight

1000 Kg

① Based on a theoretical filling level of 100%. Prior to use or processing, always consult the current product data sheet of the products used

We could also customize wet & dry type rotary shotcrete pump according to your demands.



Application

WSZ-10S Dry and wet concrete shotcrete machine for sale is installed into the TBM for the pneumatic conveyance of peagravel when tunnelling with a TBM, as well as it is widely used in mines, tunnels, culverts, subways, hydropower projects, underground projects, etc.
