WGP400/80PL-E Compact grouting unit

Description:

WGP400/80PL-E compact grouting unit is a combination of grout mixer and grout pump in one base frame. The compact grouting unit is a very versatile and efficient type of equipment. Grout mixer on the high pressure grout machine produced by us, it is high speed type. The grouting mixture should always be of very high quality. With an experienced operator the cycle of charging, mixing and discharging the batch can be kept down to one minute. It is also high shear type. With fast mixing speed 1450rpm, the high rate of shear results in a mix that is fluid and stable enough to be pumped over considerable distances, and which will permeate uniformly into voids. Grout mixer pump flow and pressure are designed based on the projects request.

WGP400/80PL-E compact grout plant is mainly used to be made bentonite slurry, cement slurry, etc., in the application highway, railway, hydropower, construction, mining and other ground and underground construction.

Mobile Phone: +86-19913803800
E-mail: sales@wodetec.com

Features

1. Up to 5mm particle size.

2. Grouting pressure and displacement of this compact grouting unit is adjustable.

3. Compact grout plant is easy to operate and maintain.

4. The vertically plunger pump is a universal application for grouting.

5. The function switch between mixer and grout pump is realized by using squeeze switch.

6. WGP400/80PL-E compact grouting unit for sale is ergonomic, space saving.

compact grout plant details details of compact grouting unit details of grout plant electric cabinet of compact grout unit

electric compact grout unit handle of grout plant vertically plunger pump mixer of compact grout unit

Technical Paremeter

Name

Data

Type

WGP400/80PL-E Compact grouting unit

Mixer

Volume(L)

400

Speed(rpm)

1450

Grouting pump

Stroke (mm)

220

Cylinder diameter (mm)

120

Flow(L/min)

80

60

Pressure(MPa)

2.4

5

Power(KW)

15

Dimension

Dimension(mm)

2450×1200×1750

Weight(KG)

980



Application

Wodetec equipment are compact grouting unit supplier and compact grouting unit manufacturer for many years, WGP400/80PL-E compact grouting unit is used for all grouting applications with cement and ultra fine cement, bentonite suspensions for microtunnelling, pipe jacking and directional drilling.

compact grouting unit application
